Fitment Information

• BMW 535i/535iX/535d/535dX (F07/F10/F11/F18) N55 3.0L Turbo 2010 2011 2012 2013 2014 2015 2016
• Chassis: F07/F10/F11/F18

Specs & Features

• Direct replacement for the factory intercooler
• Twice the cooling performance of OEM
• Competition core with aluminum end tanks
• Lower pressure drop than OEM
• Bolt on installation
• Max Horsepower Capacity: 300-500HP
• Core Length: 22"
• Core Height: 8" (Lower Side), 12" (Taller Side)
• Core Thickness: 3.5"
• Inlet / Outlet Size: 2.4"
• End to End Length: 28" Approx.
• 50% more air flow volume than OEM intercooler

Rev9 Intercooler Kits are designed for those seeking the most performance potential from their cars.  Made to be direct replacements (unless otherwise noted), yet offers twice the cooling capability at a lower pressure drop than OEM to increase the cool, dense air being forced into the motor which generates more power and torque at the same boost level.
